MediaTek
Helio P60
Big core performance, incredible camera and an intelligent edge-AI infusion. Brilliance Starts Within.
MediaTek Helio P60
at‑a‑glance
Learn more about
MediaTek Helio P60
MediaTek Helio P60
versus the competition
MediaTek Helio P60
The MediaTek Helio P60 brings together a deep and diverse mix of class‑leading hardware. It combines the incredible power of four, big Arm Cortex‑A73 processors among its octa‑core CPU; a multicore AI Processor (NPU) for efficient edge‑AI processing; the latest Arm Mali‑G72 GPU; 20:9 FullHD+ display support; and three power‑optimized ISPs and other hardware‑enhancements paired to supersized cameras.
This is all produced on TSMC 12nm FinFET production process, and when combined with MediaTek CorePilot 4.0 provides class‑leading performance and power‑efficiency.
Multi‑Core NPU
MediaTek Helio P60 brings NeuroPilot™ intelligence to the heart of your smartphone. Its heterogeneous AI‑compute architecture works seamlessly across CPU, GPU and NPU within the SoC.
The NPU includes multi‑core processor combined with an intelligent control logic. It is 2X more power efficient than a GPU and generates class‑leading edge‑AI processing performance of up to 280GMAC/s.
Applications can be built using common frameworks such as TensorFlow, TF Lite, Caffe and Caffe2 or other 3rd party frameworks, and at the API level standard Google Android Neural Networks API (Android NNAPI), while the NeuroPilot SDK extensions allow developers and device makers to bring their code closer-to-metal for better performance and power-efficiency.
Key Features
In conjunction with the P60’s incredible camera technology, users can enjoy AI-infused experiences in apps with deep-learning facial detection (DL-FD), real-time beautification, novel, real-time overlays, object and scene identification, AR/MR acceleration, enhancements to photography or real-time video previews and much more.
Bringing the power of big core performance to Android smartphones, the new octa-core CPU boosts performance in demanding applications and combined with the new Arm Mali-G72 MP3 GPU at up to 800MHz boosts games up to 70% vs previous generation P series.
These high-performance CPU’s and GPU’s require plenty of memory bandwidth, so the MediaTek Helio P60 provides up to 8GB of ultra-fast, yet highly power-efficient LPDDR4X at 1,800MHz.
The SoC hardware is fabricated on the latest TSMC 12nm FinFET production process, which is up to 15% lower power than other 14nm products and brings the performance close to 10nm generation products.
Power management is critical to provide the best possible user experience and MediaTek CorePilot 4.0 provides Thermal Management, UX Monitoring and Energy Aware Scheduling to focus on maintaining a sustainable, high performance user experience.
Compared to previous generation P series, the Helio P60 is up to 12% more power efficient overall and up to 25% in highly demanding games, allowing you to play for much longer.
MediaTek Helio P60 smartphones can combine up to a 24+16MP dual camera array or single 32MP shooter. It’s hardware-driven, high resolution depth engine gives a 3X boost in depth-mapping performance, enabling real-time depth of field (bokeh) calculations.
With three, power-optimized ISPs it saves up to 500mW, equating to 18% over the previous generation. Working together they can fuel a supersized 32MP sensor at 30fps with zero shutter delay (ZSD), or a 16MP sensor at 90fps for ultra-fast, multi-frame recording.
When preparing to shoot any kind of picture or video, MediaTek Helio P60 can auto-detect, process, display and record HDR images in real-time - allowing you to see exactly what you’ll shoot – with embedded auto-enhancements such as multi-frame noise reduction, RAW-domain multi-frame HDR, Zig-Zag HDR and PDAF.
Further hardware enhancements include a hardware warping engine used for electronic image stabilization (EIS); an anti-blooming engine preventing white-out; accurate face detection and intelligent scene detection for better 3A (AE, AF and AWB) and MEMA 3DNR.
MediaTek 4G LTE WorldMode modem focuses a power efficient design with latest cellular features and standards, such as IMS (VoLTE\ViLTE\VoWi-Fi), which is now supported by over 100 cellular operators world-wide; global eMBMS, and HPUE and 600MHz (Band 71) frequency support in North America.
Dual 4G, Dual VoLTE is available, where VoLTE and ViLTE provide the best possible call and live video experience, with faster call setup time noticeably better sound quality.
With 4G LTE benefits, the second SIM also has faster connectivity, more reliable coverage and lower power consumption than previous generation products, it meets the needs of 4G-only operators and is future proof as 2G/3G networks are progressively retired.
MediaTek’s innovative Transmission Antenna Switching (TAS 2.0) technology enhances the user experience by using the best antenna combination to provide optimal and sustained signal quality at lowest power. This provides not only a sustainably faster data connection, but it also makes smartphones safer to use.
The platform includes a Cat-7 (DL) / Cat-13 (UL) performance 4G LTE modem, while local connectivity and location services include 802.11ac Wi-Fi, Bluetooth 4.2, multi-GNSS options and FM radio.
Specifications
Processor
CPU Type(s)
- Arm Cortex-A53
- Arm Cortex-A73
Max CPU Frequency
Up to 2.0GHz
Cores
Octa (8)
CPU Bit
64-bit
Heterogeneous Multi-Processing
Yes
Memory and Storage
Memory Type
LPDDR3, LPDDR4x
Max Memory Frequency
1X LPDDR3 933MHz, 2X LPDDR4x Up to 1800MHz
Max Memory Size
Up to 8GB (LPDDR4x), Up to 4GB (LPDDR3)
Storage Type
eMMC 5.1, UFS 2.1
Connectivity
Cellular Technologies
4G Carrier Aggregation (CA), CDMA2000 1x/EVDO Rev. A (SRLTE), 4G FDD / TDD, HSPA +
Specific Functions
2x2 UL CA, TAS 2.0, HPUE, IMS (VoLTE\ViLTE\WoWi-Fi), eMBMS, Dual 4G VoLTE (DSDS), Band 71
LTE Category
Cat-7 DL / Cat-13 UL
General Connectivity
Bluetooth, FM Radio, GNSS, Wi-Fi
GNSS
Beidou, Galileo, Glonass, GPS, QZSS
Wi-Fi
Wi-Fi 5 (a/b/g/n/ac)
Bluetooth Version
4.2 (Low Energy)
Camera
Max Camera ISP
24MP + 16MP, 32MP
Max Video Capture Resolution
1920 x 1080
Capture FPS
Up to 32MP @ 30fps with ZSD or 16MP @ 90fps
Camera Features
(AI) Facial Detection & Scene Detection; Hardware Warping Engine (EIS); Anti-Blooming Engine; MEMA 3DNR; Multi-Frame Noise reduction; Real-time HDR recording and viewing; Zig-Zag HDR; RAW-domain multi-frame HDR; PDAF
Graphics
GPU Type
Arm Mali-G72 MP3
Max GPU Frequency
Up to 800MHz
Max Display Resolution
2160 x 1080
Video Encoding
H.264
Video Playback
H.264, H.265 / HEVC
MediaTek Technologies
MediaTek Technologies
CorePilot, Imagiq, NeuroPilot, Pump Express, Pump Express Wireless
AI
AI Accelerator
Yes
Performance
Up to 280GMAC/s
